SCHOTTEL SV 1 - Steering with both Systems

46 /
48
Control System and Electric System (PX 105)FIT--Wa 1159850Dec./06 en
Steering with both systems
Driving direction
Thrust direction
Steering with starboard system
Steering with port--s ide system
0
0
0
0
! CAUTION
Thrust direction is not
equal to driving direction
Figure 62
