Technical Data
18
02.00 | GWB | Assembly and Operating Manual | en | 389122
3 Technical Data
Designation GWB
34
GWB
44
GWB
54
GWB
64
GWB
80
GWB
100
Opening angle per jaw [°] 90.0
About rake angle per jaw up to [°] 2.0
Closing torque [Nm] 2.112 8.19 15.08 27.45 50 127
Ensured by spring closing torque [Nm] 0.5 1.8 2.9 5.2 10.5 31.8
Weight [kg] 0.14 0.34 0.56 0.85 1.6 3.5
Recommended workpiece weight [kg] 0.3 0.9 1.4 2.2 2.7 6.0
Air consumption per double stroke [cm3] 4.5 16.0 36.0 57.0 110.0 217.0
Nominal working pressure [bar] 6.0
Min. pressure [bar] 4.0
Max. pressure [bar] 6.5
Closing time [s] 0.3 0.4 0.6 0.6 0.7 0.55
Opening time [s] 0.4 0.5 0.7 0.7 0.8 0.7
Max. permissible finger length [mm] 40.0 50.0 60.0 80.0 100.0 125.0
Max. permitted weight per finger [kg] 0.07 0.12 0.2 0.32 0.6 1.2
IP rating 20
Min. ambient temperature [°C] -10
Max. ambient temperature [°C] 90.0
Repeatability [mm] 0.1
Noise emission [dB(A)] ≤ 70
Pressure medium Compressed air, compressed air quality
according to ISO 8573-1:7 4 4
More technical data is included in the catalog data sheet.
Whichever is the latest version.
