SCHUNK GWB Series - Disassembly and Assembly; Disassembling the GWB 34 - 80 Module

Maintenance
34
02.00 | GWB | Assembly and Operating Manual | en | 389122
6.4 Disassembly and assembly
6.4.1 Disassembling the GWB 34 - 80 module
Position of the item numbers Assembly drawing [
}
39]
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
Ø Remove the compressed air line.
Ø Screw the upper part (2) and lower part (1) apart with the four
screws (16).
WARNING
In the event of a defect, the parts may be under spring tension.
Clamp the gripper between "a" and "b" before screwing it
apart. Then unclamp it carefully.
Ø Carefully remove the screw (18) and the underlying sealing disk (24).
