Maintenance
36
02.00 | GWB | Assembly and Operating Manual | en | 389122
6.4.2 Disassembling the GWB 100 module
Position of the item numbers Assembly drawing [
}
39]
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
WARNING
Risk of injury due to spring forces!
The cover is under spring tension.
• Carefully disassemble the product.
Ø Remove the bar (9) with the screws (29).
Ø Place a workpiece with a length of 64 mm between the fingers (3).
Ø Remove the compressed air lines.
