Technical Data
02.00 | GWB | Assembly and Operating Manual | en | 389122
19
3.1 GWB 100 gripping force diagram
GWB 100 gripping force diagram
3.2 Max. permissible forces and moments on the claw jaws /
max. finger length of the GWB 100
GWB 100
