SCHUNK GWB Series - 4 Assembly; Connections; Mechanical Connection

Assembly
20
02.00 | GWB | Assembly and Operating Manual | en | 389122
4 Assembly
4.1 Connections
4.1.1 Mechanical connection
WARNING
Risk of injury when the machine/system moves unexpectedly!
Switch off power supply.
Evenness of the
mounting surface
The values apply to the whole mounting surface to which the
product is mounted.
Requirements for evenness of the mounting surface (Dimensions in mm)
Edge length Permissible unevenness
< 100 < 0.02
> 100 < 0.05
