SCHUNK GWB Series - Servicing and Assembling the Module; Screw Tightening Torques

Maintenance
38
02.00 | GWB | Assembly and Operating Manual | en | 389122
6.5 Servicing and assembling the module
Position of the item numbers Assembly drawing [
}
39]
WARNING
Risk of injury due to spring forces!
The cover is under spring tension.
• Carefully disassemble the product.
Maintenance
• Clean all parts thoroughly and check for damage and wear.
• Treat all greased areas with lubricant. Lubricants/Lubrication
points (basic lubrication) [
}
33]
• Oil or grease bare external steel parts.
• Replace all wear parts / seals.
– Position of the wearing parts Assembly drawing [
}
39]
– Seal kit Sealing kit [
}
8]
Assembly
Assembly takes place in the opposite order to disassembly.
Observe the following:
GWB 34- 80: The flat place on the axis (13) must point in the
direction of the set-screw (20).
GWB 100: The flat place on the axis (8) must point in the direction
of the set-screw (32).
• Unless otherwise specified, secure all screws and nuts with
Loctite no. 243 and tighten with the appropriate tightening
torque. Screw tightening torques [
}
39]
