Assembly
30
02.00 | GWB | Assembly and Operating Manual | en | 389122
Type Max. finger length Nominal gripping force
L in mm Lo in mm Po in mm
GWB 34 40 21 64
GWB 44 50 31 180
GWB 54 60 33 290
GWB 64 80 40 450
GWB 80 100 67 550
