SCHUNK JGP-P - Page 24

Assembly and settings
24 02.00 | JGP-P | Assembly and Operating Manual | en | 1469637
Item Mounting JGP-P
125 160 200 240 300
Side A
1 Mounting screw M8 M8 M10 M12 M16
Max. depth of engagement
from locating surface [mm]
for variants I.D./O.D.
20
20
20.5
20
20
20
25.5
25
31
31
2 Centering sleeve Ø12 Ø12 Ø14 Ø16 Ø22
Side B
4 Bore for mounting screws M6 M6 M8 M10 M12
Mounting screw according
to standard
DIN EN ISO 4762
2 Centering sleeve Ø12 Ø12 Ø12 Ø16 Ø22
Side C
5 Bore for mounting screws M8 M8 M10 M12 M16
Mounting screw according
to standard
DIN EN ISO 4762
Max. strength class 8.8
3 Centering sleeve Ø12 Ø12 Ø14 Ø16 Ø22
