Technical Data
18
14.00 | JGP | Assembly and Operating Manual | en | 389157
3 Technical Data
Connection data
Designation JGP
Pressure medium Compressed air, compressed
air quality according to
ISO 8573-1:7 4 4
Nominal working pressure [bar] 6
Minimum pressure [bar]
without gripping force maintenance
with gripping force maintenance
2.5
4
Max. pressure [bar]
without gripping force maintenance
with gripping force maintenance
8
6.5
Pressure range for air purge [bar] 0.5 - 1
More technical data is included in the catalog data sheet.
Whichever is the latest version.
Environmental and operating conditions
Designation JGP
Ambient temperature [°C]
min.
max.
+5
+90
IP protection class * 40
Noise emission [dB(A)] ≤ 70
* For use in dirty ambient conditions (e.g. sprayed water, vapors,
abrasion or processing dust) SCHUNK offers corresponding
product options as standard. SCHUNK also offers customized
solutions for special applications in dirty ambient conditions.
