SCHUNK JGP - Tightening torque for screws; Assembly drawing

Maintenance
54
14.00 | JGP | Assembly and Operating Manual | en | 389157
7.4.2.4 Tightening torque for screws
Position of the item numbers, Assembly drawing [
}
54]
Screw tightening torques
Item JGP 40 JGP 50 JGP 64 JGP 80
JGP 100 JGP 125 JGP 160
JGP 200 JGP240 JGP 300
40 2.2 Nm 2.2 Nm 5.9 Nm 10 Nm 10 Nm 24 Nm 47 Nm 75 Nm 75 Nm 120 Nm
41 0.73 Nm 1.3 Nm 1.3 Nm 3 Nm 3 Nm 6 Nm 6 Nm 6 Nm 6 Nm 6 Nm
45 2.2 Nm 2.2 Nm 10 Nm 17 Nm 17 Nm 41 Nm 83 Nm 116 Nm 116 Nm 150 Nm
46 0.73 Nm 1.3 Nm 1.3 Nm 3 Nm 2.9 Nm 6 Nm 6 Nm 25 Nm 25 Nm 25 Nm
7.5 Assembly drawing
The following figure is an example image.
It serves for illustration and assignment of the spare parts.
Variations are possible depending on size and variant.
