Maintenance
46
14.00 | JGP | Assembly and Operating Manual | en | 389157
7.3 Lubricants/Lubrication points
SCHUNK recommends the lubricants listed.
Lubricant point Lubricant
Metallic sliding surfaces microGLEIT GP 360
All seals Renolit HLT 2
Bore hole at the piston Renolit HLT 2
During maintenance, treat all greased areas with lubricant. Thinly
apply lubricant with a lint-free cloth.
The guides in the housing can be re-lubricated as needed. Remove
the set-screw of the air purge connection and replace it with a
lubrication nipple.
7.4 Disassembly and assembly
7.4.1 Disassemble the product
7.4.1.1 Variant without maintenance of gripping force
Position of the item numbers, Assembly drawing [
}
54].
Ø Remove the compressed air hoses.
Ø Remove the cover (5).
Ø Mark the installation position of the piston (3) and the base
jaws (2) in the housing (1).
Ø Unscrew the screws (41) and remove the cover (4).
Ø Unscrew the screws (40) and remove the cylinder piston (60)
from the housing (1).
Ø Press the piston (3) upward out of the housing (1).
Ø Pull the base jaws (2) out of the housing (1).
