7.4.2 Assembling the product
7.4.2.1 Notes for assembly
Assembly takes place in the opposite order to disassembly.
Observe the following:
• For variant with "O.D. gripping" maintenance of gripping force (AS):
– Sizes 40-100: assemble cylinder piston using an assembly
device, Assembly with assembly device [
}
50].
– Size 125: assemble in the reverse order without assembly
device.
– Sizes 160-300: assemble cylinder piston using two assembly
devices, Assembly with assembly device [
}
50].
• Unless otherwise specified, secure all screws and nuts with
Loctite no. 243 and tighten with the appropriate tightening
torque. Tightening torque for screws [
}
54]
