Assembly
34
14.00 | JGP | Assembly and Operating Manual | en | 389157
Position "Gripper closed" or "Part gripped (O.D. gripping)"
Ø Slide the sensor2 (1) into the bracket (2) until it stops.
Ø Tighten the screw (3) on the bracket (2).
Tightening torque: 0.2 Nm
Ø Close gripper or grip part.
Ø Unfasten the screw (4).
Ø Turn the screw (5) to adjust the position of the control cam (6).
✓ Slide control cam (6) outwards until the sensor 2 (1) no
longer responds.
Move the control cam (6) back towards the inside until the
sensor 2 (1) begins to switch.
Ø Tighten screw (4) while pressing the control cam in the direction
of the gripper fingers. IMPORTANT!The control cam may tilt in
the guide if it has not been tightened properly.
✓ Switching point is set.
Ø Bring product into the "Gripper closed" or "Part gripped"
position and test the function.
NOTE
If the switching position cannot be queried, it may be that the
alignment of the control cam has to be changed, Turn control
cam [
}
28].
