Tightening torques for screws
4 Tightening torques for screws
Tightening torques to mount the clamping system on the
machine table (screw quality 10.9)
Screw size
M4
M5
M6
M8
M10
M12
M14
M16
M18
M20
M22
M24
Tightening torque
M
A
(Nm)
4.2
7.5
13
28
50
88
120
160
200
290
400
500
Tightening torque for mounting top jaws on the TANDEM
clamping force block (screw quality 12.9)
Screw size
M4
M5
M6
M8
M10
M12
M14
M16
M20
M24
Tightening torques
M
A
(Nm)
5
9
15
32
62
108
170
262
510
880
Tightening torques to mount the chuck piston onto the cylinder
piston (screw quality 12.9)
Designation
Screw size
M5
M8
M10
M12
KSP3 / KSP3-LH
Tightening torque M
A
(Nm)
9
32
62
108
KSP3-F
Tightening torque M
A
(Nm)
4
25
50
90
Tightening torques for mounting the cover on the body (screw
quality A2-70)
Size
64
100
140
160
250
Screw size
M3
M5
M5
M5
M6
Tightening torque M
A
(Nm)
0.8
3
3
3
6
