SCHUNK KSP3 - Assembly Device

Maintenance and care
36
02.00 | KSP3, KSP3-LH, KSP3-F | Assembly and Operating Manual | en |
1463318
7.4.4 Assembly device
Dimensio
n
Sizes
64
100
140
160
250
Ød1
60.5
97.5
137.5
155.5
245
Ød2
47
79
118
135
219
Ød3
28
40
57
77
123
Ød4
10
10
12
12
12
Ød5
3.4
5.5
5.5
5.5
6.6
T1
7.4
5
6.5
8.5
10.5
T2
5.4
3
3.5
6
7.5
T3
2.7
1.8
3
4.1
5
A
11.8
38.9
45.5
39
93.8
B
11.8
38.9
36
49.8
93.8
C
27
43.5
63.5
72
116
D
24.5
19.4
44
60.5
68.3
E
24.5
19.4
52
52
68.3
F
11.8
34.3
45.5
39
93.8
G
24.5
26.8
44
60.5
68.3
