Sealing kits, accessory kits and parts lists
8 Sealing kits, accessory kits and parts lists
When ordering spare parts, the type
, size and, if possible, the serial number of the
clamping block must always be stated to avoid delivery mistakes.
Seals, sealing elements, screw connections, springs, bearings,
screws, wiper bars and parts that come into contact with the
workpiece are not covered by the warranty.
8.1 Sealing kit lists
There are two sealing kits. One for the piston chamber (piston
chamber sealing kit) and one for the pneumatic monitoring
(monitoring sealing kit). The sealing elements for the bottom
connections are included in both sealing kits.
8.1.1 Piston chamber sealing kit
The sealing kit for the piston chamber contains all seals for the
parts installed inside (e.g. cylinder pistons), as well as the O-rings
of the bottom connections.
* For included items, see column > y < in the Parts List chapter
below.
Wearing parts - replacement when maintenance is performed is
recommended
The sealing kit can only be ordered as a compete kit.
8.1.2 Monitoring sealing kit / connection
The sealing kit for monitoring includes all seals and wear parts for
the pneumatic monitoring of the PM variants, as well as the O-
rings of the bottom connections.
