SCHUNK KSP3 User Manual

Assembly and connection
02.00 | KSP3, KSP3-LH, KSP3-F | Assembly and Operating Manual | en |
1463318
23
5.3.3 Air coupling in top jaw (variant "PM")
An air coupling in top jaw 1 is integrated via connection 2 on the
bottom and an air coupling in top jaw 2 via connection 3.
Dimension
Size
64
100
140
160
250
KTR
KTR-H
KTR
KTR-H
KTR
KTR-H
KTR
KTR-H
KTR
KTR-H
B1 [mm]
4.5
4.5
14
14
18.5
18.5
28
28
36
36
B2 [mm]
18
18
35
35
46.5
41.5
56
51
80
75
T1 [mm]
11
30
18
43
27
62
30
70
35
85
T2 [mm]
4
23
9
34
15
50
19
59
21
71
Ø C [mm]
2
2
2
2
2
D [mm]
7.3
6
6
5
20
E [mm]
3.5
5.5
1
1
1
F [mm]
2 +0.1
2 +0.1
2 +0.1
2 +0.1
2.5 +0.1
Non-tolerated dimensions according to DIN ISO 2768mH.
When using top jaws type STR / STR-H / STR-S, it is essential to
observe dimension E.
Use for cleaning the clamping surfaces
The customer can create channels in the top jaw in order to clean
the clamping and bearing surfaces by means of compressed air.
Work surface
1
