02.00 | KSP3, KSP3-LH, KSP3-F | Assembly and Operating Manual | en |
1463318
Sealing kits, accessory kits and parts lists
* For included items, see column > y < in the Parts List chapter
below.
Wearing parts - replacement when maintenance is performed is
recommended
The sealing kit can only be ordered as a compete kit.
8.2 Accessory kits
Accessory kit **
ID number
Size 64
1432277
Size 100
1428583
Size 140
1428599
Size 160
1428591
Size 250
1428597
** For included items, see column > z < in the Parts List chapter
below.
8.3 Parts lists
Parts list "Standard stroke" and "Long stroke" variants
Item
Designation
Quanti
ty
a
b
c
d
e
f
y
z
1 *
Body >Housing<
1
●
2 *
Base jaw
2
●
3
Chuck piston
1
●
4
Cylinder piston
1
●
5
Cover
1
●
6
Guide strip
2
●
7
Monitoring piece
2
●
8
Covering strip
1
●
21
Lubrication nipple
4
●
●
21
Conical lubrication
nipple
4
●
●
●
22
Sound absorber
2
●
23
Locking screw
2
●
24
Steel ball
2
●
☐
26
Compression spring
4
●
☐
27
Compression spring
2
●
☐
28
Compression spring
set
4
●
8
●
●
●
●
34
Cylindrical pin
2
●
