4.2 Pneumatic connection
CAUTION
Observe the requirements for the air supply
}3 [
/
17].
• Open only the air connections that are needed.
• Close unused main air connections using the screw plugs from
the enclosed pack.
• For a hose-free direction connection, use the O-rings from the
enclosed pack.
4.2.1 OSE 14
air connections
air connections variant without pneumatic center position (M)
air connections variant pneumatic center position (M)
