Assembly and settings
24 03.00 | OSE | Assembly and Operating Manual | en | 1373804
Rotary transmission
lead through
OSE 22 - 40
OSE 45 - 57: Pinion-view with swivel unit on back stop counterclockwise, connections on the left side.
