3 Technical data
3.1 Basic data
SWS Weight [kg]
Recommended
handling
weight [kg]
Max. moment [Nm]
SWK SWA M
x
and M
y
M
Z
001 0.03 0.02 1.4 2.8 3.45
005 0.27 0.09 8 37.5 51
007 0.16 0.08 16 75 102
011 0.13 0.09 16 75 102
011HM 0.29 0.09 16 20.3 12.4
020 0.69 0.32 25 169.5 220
020HM 0.68 0.32 25 56.5 78
021 0.5 0.3 25 169.5 230
021HM 0.7 0.3 25 56.5 78
040Q 1.27 0.6 50 471 648
041 1.4 0.7 50 471 648
046 1.95 1.03 50 678 882
060 1.3 0.7 75 591 326
071 1.8 1.3 79 1185 378
076 2.25 1.4 100 1626 2103
110 4 2.2 150 2352 2352
160 6.44 2.86 300 7170 3800
More technical data is included in the catalog data sheet.
Whichever is the latest version.
