Maintenance
12.00 | SWS | Assembly and Operating Manual | en | 389456
97
7.6.2 Change O-ring
Change O-ring
Ø Place the SWA in the storage rack, secure and uncouple it.
Ø Switch off the power supply and ensure that there is no residual
energy in the system.
Ø Remove the compressed air hose.
Ø Disassemble the SWK from the robot and safely set the SWK
aside, Removing the product from the robot arm [
}
90].
Ø Remove damaged O-ring(1).
Ø Lightly lubricate the new O-ring(1),
Lubricants/greasing areas [
}
89].
Ø Carefully insert the O-ring(1) into the bore up to the stop.
