SCHUNK SWS 005 User Manual

Assembly
84
12.00 | SWS | Assembly and Operating Manual | en | 389456
5.4.5 Wrench sizes and tightening torques
Installing detection shaft
SWS
Wrench size (SW) of hexagon socket
wrench [mm]
Max. tightening
torque [Nm]
Cam Detection shaft
011 3 2.5 1.36
020 4 2.5 1.36
021 4 2.5 1.36
041 4 3 1.69
060 5 3 1.69
071 5 3 1.69
Mount SWK to adapter plate for sensor assembly
SWS
Wrench size (SW) of
hexagon socket
wrench [mm]
Fastening
screw
Max. tightening
torque [Nm]
011 2 M3 1.13
020 2.5 M4 1.13
021 2.5 M4 1.13
041 3 M5 5.08
060 4 M6 6.78
071 4 M6 6.78
