Design and description
22
12.00 | SWS | Assembly and Operating Manual | en | 389456
4.2
Design
4.2.1
SWS 001
SWK
SWK robot side
SWA locking interface
Design SWK 001
1
Pneumatic feed-through with O-ring
2
Optional module
3
Alignment pin
4
Locking mechanism
5
Dowel pin
6
Air supply lock and unlock
SWA
SWA locking interface
SWA tool side
Design SWA 001
1
Port for pneumatic feed-through
2
Centering / locking sleeve
3
Dowel pin
4
Optional module
