Assembly
12.00 | SWS | Assembly and Operating Manual | en | 389456
47
Ø Insert dowel pin on SWK(6) into the bores on the adapter
plate(3).
Ø Apply screw lock to screws(7).
Ø Fasten SWK(6) to adapter plate(3) with screws(7).
✓ Observe the tightening torque for the mounting screws.
Item Mounting SWK020HM/021HM
7 Mounting screw according to
standard
M4x30,
DIN EN ISO 4762
Strength class 12.9
Max. tightening torque [Nm] 1.69
Threadlocker Loctite ® 222
