Assembly
50
12.00 | SWS | Assembly and Operating Manual | en | 389456
Ø Insert the SWK(6) with dowel pins(5) into the bores on the
adapter plate.
Ø Apply screw lock to screws(7).
Ø Fasten SWK(6) to adapter plate(3) with screws(7).
✓ Observe the tightening torque for the mounting screws.
Item Mounting SWK040Q
5 Alignment pin Ø6 x 20
7 Mounting screw according to
standard
M5x45,
DIN EN ISO 4762
Strength class 12.9
Max. tightening torque [Nm] 5.88
Threadlocker Loctite ® 242
