SDKELI BLPS-D3L - ST Controller Technical Parameters

- 15 -
Socket pin
1
2
3
4
5
6
Signal
definition
VCC
GND
CANH
CANL
OSSD1 (L1)
OSSD2(L1)
Wire color
Red
Green
Yellow
Black
Blue
Brown
Socket pin
7
8
9
10
11
12
Signal
definition
PE
-
OSSD1 (L2)
OSSD2(L2)
OSSD1 (L3)
OSSD2(L3)
Wire color
Yellow&Gre
en
-
White
Gray
Cyan
Purple
Cable specifications list
：
Usage
Name
Specifications
Number
Connecting devices
Standard line
length
Sensor
used alone
Double-end cable
CTK6X1S090C
1
Emitter to Receiver
9m
Single-end cable
CTBLX1D050C
1
Receiver to Bending
machine
5m
Sensor
used with
SR / SP
controller
Double-end cable
CTK6X1S090C
1
Emitter to Receiver
9m
Double-end cable
CTBLX1S050C
1
Receiver to Controller
5m
Power cable
CPSRX1X050C
1
Controller to Bending
machine
5m
Signal cable
CPSRX2X050C
1
Controller to Bending
machine
5m
Sensor
used with
ST
controller
Double-end cable
CTK6X1S090C
1
Emitter to Receiver
9m
Double-end cable
CTBLX1S050C
1
Receiver to Controller
5m
Power cable
CPSRX1X050C
1
Controller to Bending
machine
5m
Signal cable
CPSTX2X050C
1
Controller to Bending
machine
5m
Note 1: the total length of two transmission lines of each set of products is not more than 40m, and
the cable length can be customized according to the actual demand.
Note 2: the power supply wire and signal wire used by SP controller are the same as SR type
controller.
