Environmental characteristics
Ambient
temperature
Operation：-10℃～55℃(without frost and
fog)
Storage：-40℃～70℃
Ambient
humidity
Operation：35%RH～85%RH
Storage: 35%RH～95%RH
Protection
level
IP65
Environmental
illuminance
Incandescent lamp:3000
Lux
Fluorescent lamp:3000
Lux
Sunlight: 10000 Lux
Homologous
light
interference
Interference light from the same design transmitter will not cause the BLPs to fail
Anti-vibration
ability
The frequency is 10-55hz, the amplitude is 0.35 ± 0.05mm, 20 times in X, y and Z
directions respectively
Impact
resistance
Acceleration 10g, pulse duration 16ms, 1000 times in X, y and Z directions
Electrical characteristics
Supply voltage
24V DC±20%
power consumption
≤3.5W
Current
consumption
Emitter
≤20 mA
Receiver
≤100 mA（Without load）
Response time
≤20ms（Complete machine, including controller）
Safety output（OSSD）
PNP output, each beam of detection light output two control signals
In on state, IOUT ≤ 100mA (6-way total ≤ 600mA), Vout ≥ vcc-2v
In off state, IOUT ≤ 1mA, Vout ≤ 2V
Function to prevent
mutual interference
Light interference avoidance algorithm
SR/SP controller technical parameters：
Project
Parameter
Ambient temperature
Operation：-10℃～55℃(without
frost and fog)
Storage：-40℃～70℃
Ambient humidity
Operation：35%RH～85%RH
Storage：35%RH～95%RH
Protection level
IP54
Dimensions
190×150×58mm
Supply voltage
AC100V～230V±10%,50/60Hz
DC24V±20%
Total power consumption
≤8.5W
Output form
Relay contact output
Output contact capacity
Contact capacity 5A, 250VAC/5A, DC24V
Start Time
<3s
Detection function
Real-time self-check
Protection circuit
The protection of overvoltage and overcurrent Output short circuit protection
