OmniHub CMP201– User Manual
Page 13 of 103
MPEG1L2, AC3 and AAC and supports
CC and analog audio input.
CE2-HDMI-05 4 channel HDMI encoding module,
supports H.264/H.265 HD/SD, MPEG-2
SD, MPEG1L2, AC3 and AAC, and
support OSD subtitle, logo picture and
QR code overlay.
CE2-HDMI-05 8 channel HDMI encoding module,
supports H.264/H.265 HD/SD, MPEG-2
SD, MPEG1L2, AC3 and AAC, and
support OSD subtitle, logo picture and
QR code overlay, each module occupies
2 slots,
CE2-CVBS-00 6 channel CVBS encoding module,
supports H.264/MPEG-2 SD, MPEG1L2.
CE2-CVBS-R01 8 channel CVBS encoding module,
supports H.264, MPEG1L2.
CE2-CVBS-R01A 16 channel CVBS encoding module,
supports H.264, MPEG1L2, the modules
occupy 2 slots.
CE2-SDI-00 2 channel SDI encoder bitrate supports
H.264/MPEG-2 HD/SD, MPEG1L2, AAC
and AC3, and supports CC and analog
audio input.
Modulator Module
Description
CM2-QAMA-R00 16 channel QAM modulator module,
Annex A/C, non-adjacent output, and 1
RF female port for output
CM2-QAMB-R00 16 channel QAM modulator module,
Annex B, non-adjacent output, and 1 RF
female port for output
CM2-QAMA-R01 4 channel QAM modulator module,
Annex A/C, adjacent output, and 1 RF
female port for output
CM2-QAMA-R01A 8 channel QAM modulation module,
Annex A/C, adjacent output, and 1 RF
female port for output
CM2-QAMB-R01 4 channel QAM modulation module,
Annex B, adjacent output, and 1 RF
female port for output
