OmniHub CMP201– User Manual
Page 61 of 103
3.3.11 CE2-SDI-00
CE2-SDI-00 module supports 2 CH H.264/AVC HD/SD (up to 1080p60) or MPEG-2 HD/SD (up
to 1080i60) encoding via SDI/CVBS input. MPEG1-L2, AAC and AC3 audio encoding, 2×BNC,
2×6-pins interfaces for analog audio inputs
3.3.11.1 Module Status
Status page for CE2-SDI show the bitrate of the source, video resolution, audio bitrate , TS
analysis and Service list on the 2 ports of the module.
3.3.11.2 Module Settings
The Setting for SDI have Basic and Advance Parameters, Basic Parameters are same with the
other Encoder Parameters where we can modify the Video, Audio and Service Parameters.
