OmniHub CMP201– User Manual
Page 25 of 103
To use Multiplexing mode on service level click on pencil icon on the right side in the line
with the proper servicename. In the next step, select the output stream (channel) where service
will be multiplexed.
Do not forget to click the Apply button on the right side to make the change takes effect.
To clear the whole routing table click button.
There is a channel scan button on top, normally the
input service list of each channel will load itself in this page, but when you change the input
source, the list could not refresh immediately. At this time, you should refresh the changed
channels manually through the operation of selecting channel and clicking Channel Scan
button.
3.2.4 IP Output
This menu allows the user to configure and access the IP output:
• Status
• Settings
• Service Configuration
Clicking on the “IP Output” gear allows to go into page where user can access Status, Setting,
Batch Setting and Service Configuration tabs related to IP output configuration. There are total
of 120 Channel output on the CMP201 Baseboard
