3.3.18.1 Module Settings
For the Settings of CM2-OFDM-R01
Module Settings is where we input the source parameters. Once done, click on apply for the
changes to take effect and check on the status in the channel signal is Locked.
Name
Range
Name
Range
Bandwidth
6M, 7M, 8M
RF level
0~31.5 (dBmV)
60~91.5 (dBuV)
Frequency (KHz)
48000~862000
