FlexZone Product Guide Page 101
Figure 94: Setting up the Remote Configuration outputs
Figure 95: Selecting the UltraLink I/O outputs
select the Remote Cfig tab
select the arrow and use the drop-down
menu to specify the appropriate output
select the Side A or Side B Cfig tab
select the arrow and use the drop-down
select the cable Segment that will activate
the UltraLink output when a sensor alarm
menu to specify the output that will activate
when the associated cable Segment detects
the processor’s 4 onboard relays are also
is detected within that segment
available in NM Mode
a sensor alarm
