Fence structures
FlexZone Product Guide Page 11
Gates
There are generally two types of gates used with fences, swinging gates and sliding gates. The
type of gate protection required is determined by:
• the type of gate
• the frequency of gate use
• when the sensor is active
• the type of ground beneath the gate
• the overall protection plan (the number of processors and sensor cables, and their location
relative to the gate in question)
Figure 3: Recommended cable installation on barbed wire
Figure 4: Razor ribbon
armored cable on barbed wire
sensor cable
bracing wire
barbed wire array
outrigger
cable tie
on fence fabric
razor ribbon
armored sensor cable
tensioning wires (2)
cable tie
