FlexZone Product Guide Page 97
b Specifications
Processor
Model processor card and enclosure
PCB dimensions (L x W) 13.2 x 14.5 cm (5.2 x 5.7 in.)
Quantity one processor per two sensor cables
Enclosure
IP66/NEMA 4 painted aluminum, outdoor rated
L x W x D 26 cm (+2.5 for cable glands) x 16 cm x 9 cm
10.25 in. (+1 for cable glands) x 6.3 in. x 3.5 in.
Cable entry ports
4 small cable ports (17 mm, 0.67 in.) fitted with 9.5 mm (3/8 in.)
compression glands: cable range: 2.9 - 7.9 mm (0.115 to 0.312 in.)
1 large cable port (22.2 mm, 0.875 in.) fitted with compression gland:
cable range: 4.3 - 11.4 mm (0.17 to 0.45 in.)
for armored cable, the 2 right side small cable ports must be drilled out
to accommodate 1/2 in. cable glands (22.2 mm, 0.875 in.)
Probability of detection
95% with a 95% confidence factor for cutting the fence, lifting the fence
fabric, or climbing over the fence unaided (based on a high quality
chain link fence, and following manufacturers’ installation and
calibration recommendations)
Maximum sensor cable
length
300 m (984 ft.) max. cable length - app. 10% less for linear fence
coverage - 270 m (886 ft.)
Power consumption 2.0 W nominal; 2.5 W nominal with NIC and option card
Power input
12 to 48 VDC (nominal)
absolute minimum 10 VDC
absolute maximum 60 VDC
min. 38 VDC input required for power over sensor cables and auxiliary
power output capability
Connectors
removable terminal block for power input
removable terminal block for relay output connections
removable terminal block for auxiliary input/self-test connections
removable terminal block for sensor cable input
USB port for UCM connection
20-pin socket for network interface card
micro SD card slot to record sensor response data to removable media
