Page 98 FlexZone Product Guide
Processor
Controls
• calibration adjustments via the Universal Configuration Module
(Windows-based software application)
Inputs
• 2 sensor cable inputs (1 per zone)
• 2 voltage sensing auxiliary device/self-test inputs
Outputs
• 4 form C relay outputs 30 VDC @ 1 A maximum, non-inductive load
user-configurable relay response
LED indicators
• power
• one per relay
• UCM connected
• Enclosure door open
• diagnostic activity
Supervision
• mechanical enclosure tamper switch
• sensor cables
• processor operation
Temperature • -40º to +70ºC (-40º to +158º F) (as measured inside the enclosure)
Relative humidity • 0 to 95%, non-condensing
