System test procedure
Page 86 FlexZone Product Guide
• Fence lift detection (This test may not be possible on all fence types. Use care to ensure that
the fence is not damaged during this test.) - Have a tester lift or pry up the bottom the fence
fabric for a minimum of the Event Time X the Event Count (depending on the amount of fence
noise being generated, the test may have to exceed the Event Time setting by several
seconds). Repeat the lift test in at least three locations per zone.
PASS ____ FAIL____
• Enclosure tamper - Open the enclosure. The DOOR OPEN LED (D1) turns ON, and the
UCM Enclosure Tamper indicator turns ON, and the Event log reports an Enclosure Tamper
alarm. If a relay is configured to activate for an enclosure tamper, the designated Relay
activates.
PASS ____ FAIL____
• Self-test - Activate the self-test for the A-side. The processor performs electronic self-tests of
the A-side. (All relays assigned to the A-Side cable should activate.)
Activate the self-test for the B-side. The processor performs electronic self-tests of the B-side.
(All relays assigned to the B-Side cable should activate.)
PASS ____ FAIL____
• Auxiliary device inputs - For Local control mode the Aux inputs activate the system self-test.
In this case, activate the appropriate switch, and verify that the self-test occurs. Repeat for
both cable sides.
For Remote control mode, the Aux inputs serve as auxiliary device inputs to the host Security
Management System. In this case, activate the connected device, and verify the status
change is reported by the host SMS. Repeat for each input.
PASS ____ FAIL____
• Relay outputs - For Local control mode the relay outputs are used to report events. Cause an
event, and verify that the specified relay activates for a minimum of the relay hold time. Repeat
this procedure for each specified event (in the Output Configuration field).
For Remote control mode, the relays serve as output control points for the host SMS. Send an
activation command from the host SMS to one of the relays and verify that the relay activates.
Repeat this procedure for each relay.
PASS ____ FAIL____
• Audio test - Activate the Audio sequentially for each configured Cable, Zone, or Cables for
the connected processor. Have a tester create a disturbance on the matching Cable, Zone, or
Cables while the corresponding Audio is activated. The fence tester and the UCM monitor
must be in contact to ensure the selected Cable, Zone, or Cables match the locations of the
tests.
When the fence tester creates the disturbance, an audio signal is produced over the PCs
audio output device.
PASS ____ FAIL____
