Use the left and right arrow buttons
to highlight the field you intend to change.
Press Enter to open the field and use the up or down arrow button to
change the signal. Press Enter again to close the field. Press to save your
changes.
NOTES:
1. For information on digital output connections see
Analog and Digital Interface.
2. Alarms go open when present and statuses go closed when active.
3. See the following tables for a list of Alarms and Statuses:
PROGRAMMABLE DIGITAL OUTPUT LIST
ALARMS_________________________________________________________________
 SampP – Sample Pressure
 AirP – Air Pressure
 OvenT – Oven Temperature
 ConvT – Converter Temperature
 PumpT – Pump Temperature
 DiodT – Diode Temperature
 CellT – Cell Temperature
 DryT – Dryer Temperature
 O2T – Oxygen Temperature
 SEPC – Sample EPC Voltage
 AEPC – Air EPC Voltage
 ROvr – Over Range
 AOvr – ADC Over Range
 AUnd – ADC Under Range
 R1NC – Range 1 not calibrated
 R2NC – Range 2 not calibrated
 R3NC – Range 3 not calibrated
 R4NC – Range 4 not calibrated
 O2NC – O
2
not calibrated
 Conc1 – Concentration Alarm 1
 Conc2 – Concentration Alarm 2
