SERVOPRO NOx Analyzers Page
199
Output Address 2 Bytes
0x0000 to 0xFFFF
Output Value 2 Bytes
0x0000 to 0xFFFF
Response
Function Code 1 Byte 0x06
Output Address 2 Bytes
0x0000 to 0xFFFF
Input Registers 2 Bytes
0x0000 to 0xFF00
Error
Error Code 1 Byte
0x86
Exception Code 1 Byte
01 or 02 or 03 or 04
EXAMPLE: Request to write Register 1 to 00 03 hex:
Request Response
Field Name (Hex) Field Name (Hex)
Function 06 Function 06
Register Address Hi 00 Register Address Hi 00
Register Address Lo 01 Register Address Lo 01
Register Value Hi 00 Register Value Hi 00
Register Value Lo 03 Register Value Lo 03
