5.8

SELECT ANALOGUE

1.1 ASSIGNED

SELECT ANALOGUE

1.1 UNASSIGNED 8

> or ? to select another output then L

ENTER

L MEASURE to return to measurement

display

Table 5.6 Clearing an analogue output assignment

L MENU to obtain top level menu

CALIBRATE/SETUP

ALARMS/FAULTS

L < ENTER

SET ALARM/ASSIGN

DISPLAY/UTILITY

L < ENTER

ENTER PASSWORD

0000

To change the value of a digit

L > or ?

To change to another digit L = or <

When the number shown is correct L ENTER

RELAYS

ANALOGUE

L ? ENTER

SELECT ANALOGUE

1.1 ASSIGNED 8

> or ? to select the required previously

assigned output analogue output then

ENTER.

ANALOGUE ASSIGN

1.1 EDIT/CLEAR

L < ENTER to clear the assignment.

SELECT ANALOGUE

1.1 UNASSIGNED

MEASURE to return to measurement

display.
