8.4
LO V/C OUTSIDE
RANGE
or
HI V/C OUTSIDE
RANGE
The gas concentration
specified in the
autocalibration
configuration is outside
of acceptable limits.
Respecify the
calibration gas
concentration.
LO CAL OUTSIDE
LIMITS
or
HI CAL OUTSIDE
LIMITS
The results of an
autocalibration are
different from the
existing values by more
than the specified
tolerance limits.
Check that calibration
gas is not empty.
Check that the
concentration of the
calibration sample
corresponds with the
concentration specified
in the autocalibration
configuration. Perform
an ONE CYCLE
autocalibration to clear
the fault. If a
successful calibration
can not be achieved
then call a service
engineer.
Table 8.4 shows a list of the diagnostic signals available for the Gfx1210 transducer.
Table 8.4 Diagnostic signals for the Gfx 1210 transducer
Fault Description Typical level Range
DIF SIG Difference signal between
the CO and N
2
filled filters
0.000V -0.25 to 1.31
V
GAS SIG Signal level for the CO
filled filter
1.000 V 0.5 to 1.31 V
N2 SIG Signal level for the N
2
filled filter
1.000 V 0.5 to 1.31 V
SAMPLE
TEMP
Sample temperature 20°C 0 to 50°C
CHOPPER
TEMP
Chopper box temperature 60 °C 50 to 70 °C
