Device structure

Device overview

Assembly and Operating Instructions – MAXO-MS/M/SM-GIOP Sensor Module

3.5 Device overview

X4251_11

X4251_12

X4111

X4101

X1512

[1]

[2]

X4030

[3]

[4]

[5]

[6]

33692952587

[1] X4251_11 EtherCAT

interface (IN)

[2] X4251_12 EtherCAT

interface (OUT)

[3] X4030 RS422 interface for connecting an external optical

track guidance (optional)

[4] X4111 CAN interface

[5] X4101 CAN interface (diagnostics)

[6] X1512 Interface for power supply

For further information, refer to chapter "Electrical installation"(→224).
