7
Technical data
General
Assembly and Operating Instructions – MAXO-MS/M/SM-GIOP Sensor Module
29
7 Technical data
7.1 General
General
Ambient temperature +5°Cto+40°C
(non-condensing, no condensation)
Storage temperature and
transportation
-25°Cto+70°C
Climate class (EN60721-3-3) 3K3
Voltage supply DC24V
Max. power/current consump-
tion
(without external optical track
guidance)
12W/0.5A
Mass 28279883 (GIP) 620g
28272528 (GIOP) 632g
Degree of protection IP54 (according to EN60529)
Installation altitude (industry
standard)
≤2000m
7.2 Track guidance
Track guidance
Tolerance ±2mm
Resolution 0.2mm
Frequency 25kHz–50kHz
Sensing range ±65mm
7.3 Rotation rate and acceleration sensors
Rotation rate and acceleration sensors
Rotation rate sensor Acceleration sensors
(g=9.81m/s
2
)
Measuring axis Ω
Z
a
x
, a
y
Measuring range ±187°/s ±4.9g
Measuring accuracy 175 LSB per°/s 6667 LSB per g
Measuring tolerance ±3% ±3%
Non-linearity ±1°/s ±40mg
Offset of controller ±3°/s ±100mg
26868113/EN – 03/2021
