Electrical installation
Electrical connections
Assembly and Operating Instructions – MAXO-MS/M/SM-GIOP Sensor Module
24
5 Electrical installation
5.1 Electrical connections
5.1.1 Representation of connections
The wiring diagrams show the contact end of the connections.
5.1.2 X4251_11/12: EtherCAT
®
/SBus
PLUS
interface
Function
EtherCAT
®
/SBus
PLUS
Connection type
Connection M12, 4-pin, female, D-coded
Connection diagram
4
2 1
3
No. Name Function
1 TX+ Transmit line (+)
2 RX+ Receive line (+)
3 TX- Transmit line (-)
4 RX- Receive line (-)
5.1.3 X4030: Connection, external optical track guidance (optional)
Function
Connection for an external optical track guidance from Leuze:
• Designation of the manufacturer: OGS 600-280/D2-M12.8
• Article number of the manufacturer: 50137476
The connection is included in the delivery of the device with the part number:
28272528.
Connection type
M12, 8-pin, female, A‑coded
Connection diagram
6
1
7
3
8
2
4
5
