Sharp ER-A421 User Manual

183
On-line Confi guration Programming
Use the following procedure to select the on-line confi guration programming.
Please consult your dealer for more details.
Procedure
▼
1.
In the SETTING window, select “16 ONLINE CONFIG”.
• The ONLINE CONFIG window will appear.
2.
Program each item as follows:
• TERMINAL NO. (Use the numeric entry)
Terminal number (1 to 999999).
• CI SIGNAL (Use the selective entry)
Sensing of the CI signal
NON
SENSING
• BAUD RATE (Use the selective entry)
Transmission data rate
57600 bps 38400 bps
19200 bps 9600 bps
4800 bps
• START CODE (Use the numeric entry)
Start code (0 to 127)
• END CODE (Use the numeric entry)
End code (0 to 127)
• TIME OUT (Use the numeric entry)
Programming of the time-out time (1 to 255 sec.)

Sharp ER-A421 Specifications

General

Memory type	Flash ROM
Types of payment	Cash
Electronic journal	Yes
Compatible memory cards	SD
Keyboard number of keys	119
Number of clerks/departments	99
Number of programmable VAT rates	6
Number of Price Look-Up codes (PLUs)	20000 PLUs
Supported paper width	58 mm
Display digits	24 digits
Display number of lines	10 lines
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	424 mm
Width	355 mm
Height	305 mm
Weight	12000 g
