MX-5001N ADJUSTMENTS 5 – 33
E
Is there a
resistance in the
section B?
Yes
No
Increase the
clearance in
the section F
until there is a
resistance in
the section B.
However, the
max. is 5.0mm.
F
F
20mm
a
4.3 - 5.0mm
c)Adjust the section F.
*
If not, turn the section E to adjust.
Use a clearance gauge to check to confirm that the clearance
in the section F is 4.3mm - 5.0mm.
Turn section E clockwisetolifttheRSPF unit.Turn it
counterclockwise to move down the RSPF unit.
*
Insert a clearance gauge in the range of 20mm from the
edge (a) of the right lower cover of the base.
Adjust the
section F so that
the clearance is
4.3mm - 5.0mm.
a
