2-74
PRINTING
DIRECTLY PRINTING A FILE IN A NETWORK FOLDER
You can use the machine
's operation panel to select and pr
int a file on a server or in a shared folder of an
individual's
computer on the same net
work as the machine.
Keys in the display can be
selected
with the arrow keys and the [OK] ke
y.
1
Press the [PRINT] key.
2
Access the network.
(1)
Select the [Ex Data Access] key.
(2)
Select the [Network Folder] key.
PRINT
OK
BACK
OK
BACK
(1)
(2)
152
154
Table of Contents
Chapter 1 Before Using the Machine
4
Operation Guide
1
Manuals Provided with the Machine
2
Printed Manuals
2
Table of Contents
4
Part Names and Functions
6
Exterior
6
Interior
8
Side and Back
9
Operation Panel
10
Using the Operation Panel
11
Using the Display
11
Entering Numbers
12
Using the Web Page
15
Turning the Power on and off
16
Energy Save Functions
17
[Power Save] Key
17
User Authentication
18
Authentication by User Number
18
Authentication by Login Name
18
Authentication by Login Name / Password
20
Accessing the Web Page
23
User Control
24
User List
24
Default Setting
27
Disable Switching of Display Order
28
Card Settings
28
Page Limit Group List
29
Authority Group List
30
Favourite Operation Group List
32
View User Count
33
Remote Operation of the Machine
34
Job Log
35
Save / Delete Job Log
35
View Job Log
35
Items Recorded in the Job Log
36
Storage Backup
38
Export Settings
38
Import Settings
38
Device Cloning
39
Export Settings
39
Import Settings
39
Loading Paper
40
Important Points about Paper
40
Names and Locations of Trays
40
Useable Paper
40
Print Side Face up or Face down
41
Tray Settings for Trays 1 to 4
43
Loading Paper and Changing the Paper Size
43
Loading Paper in the Bypass Tray
45
Important Points When Using the Bypass Tray
46
Loading Envelopes
47
Peripheral Devices
48
Finisher
49
Part Names
49
Supplies
49
Sharp Osa
50
Standard Application
50
External Account Application
51
Replacing the Toner Cartridges
52
Replacing the Toner Collection Container
55
Replacing the Developer Cartridge / Drum Cartridge
58
Replacing the Developer Cartridge
58
Remove the Developer Cartridge
59
Turn on the Power
62
Replacing the Drum Cartridge
63
Replacing the Staple Cartridge in the Finisher
65
Regular Maintenance
67
Cleaning the Main Charger of the Photoconductive Drum
67
Clean the Main Charger
68
Cleaning the Bypass Feed Roller
70
Cleaning the Laser Unit
72
Laser Unit
74
Cleaning the Pt Charger
76
Entering Text
78
Functions of the Main Keys
78
Chapter 2 Printing
80
Printer Function of the Machine
82
Printing from Windows
83
Basic Printing Procedure
83
Selecting the Paper
85
Printing on Envelopes
86
Printing When the User Authentication Function Is Enabled
87
Start Printing
88
Viewing Printer Driver Help
89
Saving Frequently Used Print Settings
90
Saving Settings at the Time of Printing
90
Using Saved Settings
92
Changing the Printer Driver Default Settings
93
Printing from a Macintosh
95
Basic Printing Procedure
95
Selecting Paper Settings
95
Printing
96
Selecting the Paper
98
Printing on Envelopes
99
Printing When the User Authentication Function Is Enabled
100
Frequently Used Functions
102
Selecting the Colour Mode
102
Black and White Printing
103
Selecting a Print Mode Setting
104
Two-Sided Printing
105
Fitting the Print Image to the Paper
107
Printing Multiple Pages on One Page
108
Stapling Output
110
Convenient Printing Functions
112
Convenient Functions for Creating Pamphlets and Posters
112
CREATING a PAMPHLET (Pamphlet)
112
INCREASING the MARGIN (Margin Shift)
114
CREATING a LARGE POSTER (Poster Printing)
115
Functions to Adjust the Size and Orientation of the Image
116
ROTATING the PRINT IMAGE 180 DEGREES (Rotate 180 Degrees)
116
ENLARGING/REDUCING the PRINT IMAGE (Zoom/Xy-Zoom)
117
ADJUSTING LINE WIDTHS WHEN PRINTING (Line Width Settings)
118
REVERSING the IMAGE (Mirror Image)
119
Colour Mode Adjustment Function
120
ADJUSTING the BRIGHTNESS and CONTRAST of the IMAGE (Colour Adjustment)
120
PRINTING FAINT TEXT and LINES in BLACK (Text to Black/Vector to Black)
121
SELECTING COLOUR SETTINGS to MATCH the IMAGE TYPE (Advanced Colour)
122
Functions that Combine Text and Images
124
ADDING a WATERMARK to PRINTED PAGES (Watermark)
124
PRINTING an IMAGE over the PRINT DATA (Image Stamp)
125
CREATING OVERLAYS for PRINT DATA (Overlays)
126
Print Functions for Special Purposes
127
PRINTING SPECIFIED PAGES on DIFFERENT PAPER (Different Paper)
127
ADDING INSERTS WHEN PRINTING on TRANSPARENCY FILM (Transparency Inserts)
129
PRINTING a CARBON COPY (Carbon Copy)
130
TWO-SIDED PRINTING with SPECIFIC PAGES PRINTED on the FRONT SIDE (Chapter Inserts)
131
Retention (Print Hold) Function
132
SAVING PRINT FILES (Retention)
133
Printing a Stored File
135
Automatically Print All Stored Data
137
Print Settings Screen
138
Multi-File Printing
139
Printing a Selected File
140
Batch Printing
141
To Change the Number of Copies
143
Deleting a Stored File
144
Automatic Deletion of Files
145
Searching for a Stored File
146
Printing Without the Printer Driver
148
Directly Printing from the Machine
148
Directly Printing a File on an Ftp Server
149
Directly Printing a File in Usb Memory
151
Directly Printing a File in Anetwork Folder
153
Directly Printing from a Computer
156
Submit Print Job
156
Ftp Print
156
E-Mail Print
157
Checking the Print Status
158
Job Status Screen
158
Spool Screen/Job Queue Screen/Completed Job Screen
158
Printing an Encrypted Pdf File
160
Giving a Print Job Priority/Cancelling a Print Job
161
Giving a Print Job Priority
161
Cancelling a Print Job
162
Changing to Another Paper Size and Printing When Paper Runs out
163
Retrieving and Using a File from the Job Status Screen
165
Appendix
167
Printer Driver Specification List
167
Chapter 3 System Settings
169
System Settings
171
Configuring the System Settings
172
Common Operation Methods
173
Accessing the Web Server in the Machine
174
Opening the Web Pages
174
System Settings (General) on the Operation Panel
175
Accessing the System Settings (General)
175
System Settings (General) List
176
Display Contrast
178
Total Count
178
Job Count
178
Device Count
178
Default Settings
179
Clock Adjust
179
Daylight Saving Time Setting
179
Date Format
180
Keyboard Select
180
List Print (User)
180
Paper Tray Settings
181
Tray Settings
181
Paper Type Registration
183
Auto Tray Switching
183
Custom Size Registration (Bypass)
183
USB-Device Check
183
Accessing the System Settings (Administrator)
184
When User Authentication Is Not Enabled
184
When User Authentication Is Enabled
185
System Settings (Administrator) List
188
System Settings (Administrator) on the Operation Panel
184
Energy Save
191
Toner Save Mode
191
Preheat Mode Setting
191
Operation Settings
192
Other Settings
192
Machine Display Pattern Setting
192
Device Control
192
Network Settings
193
Ipv4 Settings
193
Ipv6 Settings
193
List Print (Administrator)
194
Security Settings
195
Ssl Settings
195
Ipsec Settings
195
Product Key
196
Serial Number
196
Application Integration Module
196
Storing/Calling of System Settings
197
Restore Factory Defaults
197
Store Current Configuration
197
Restore Configuration
197
Sharp OSA Settings
198
External Account Setting
198
Job Priority Preference
198
Usb Driver Settings
198
System Settings (General) in the Web Page
199
System Settings (General) List
199
Total Count
202
Job Count
202
Device Count
202
Default Settings
203
Clock Adjust
203
Keyboard Select
204
List Print (User)
204
Paper Tray Settings
205
Auto Tray Switching
205
Tray Settings
205
Custom Size Registration (Bypass)
208
Paper Type Registration
208
Printer Condition Settings
209
Printer Default Settings
209
PCL Settings
210
Postscript Setting
211
USB-Device Check
211
System Settings (Administrator) in the Web Page
212
Accessing the System Settings (Administrator)
212
When User Authentication Is Not Enabled
212
When User Authentication Is Enabled
212
System Settings (Administrator) List
212
System Settings (Administrator) List
213
Device Control
214
Printer Settings
215
System Settings
217
Energy Save
219
Operation Settings
220
Disabling of Job Priority Operation
220
Auto Clear Setting
220
Disabling of Bypass Printing
220
Key Operation Setting
220
Message Time Setting
220
Disabling of Clock Adjustment
220
Remote Operation Settings
221
Soft Keyboard Template Setting
221
Device Control
222
Disabling of Duplex
222
Auto Paper Selection Setting
222
Disabling of Stapler
222
Easy Calibration
223
Colour Balance
224
Printer Settings
226
Default Settings
226
Prohibit Notice Page Printing
226
Bypass Tray Settings
226
Prohibit Test Page Printing
226
Cmyk Exposure Adjustment
226
Job Spool Queuing
226
Print Density Level
226
Interface Settings
227
Print Hold Setting
228
Batch Print Settings
228
Automatic Deletion of File Settings
228
List Print (Administrator)
229
Sharp OSA Settings
229
Administrator Settings List
229
Enable/Disable Settings
230
Operation Settings
230
Printer Condition Settings
230
Product Key
231
Appendix
232
System Settings Menu (Operation Panel)
232
System Settings Menu (Web Page)
233
Chapter 4 Troubleshooting
234
Removing Misfeeds
235
How to Remove Misfeeds
236
Removing Staple Jams
239
Finisher
239
Printing
241
Troubleshooting
241
Problems Related to Printing Operation
242
Problems Related to Print Results
244
Problems Related to Filing
247
Problems Related to File Management
247
General Problems
248
Problems Related to Machine Operation
249
Problems Related to Paper Feeding and Output
251
Problems Related to Quality / Print Results
252
Problems Related to Peripheral Devices
254
The Connected USB Device Cannot be Used
254
The Connected USB Memory Cannot be Used
254
The Finisher Does Not Operate
254
Stapling Does Not Take Place
254
Output Does Not Collect Neatly in the Output Tray of the Finisher
254
Stapled Output Does Not Collect Neatly
255
Other Problems
255
The Display Screen Is Difficult to View
255
You Were Logged out Without Having Performed Logout Yourself
255
You Forgot the Administrator Password
255
The Actuator Came off (When a Finisher Is Not Installed)
255
Other manuals for Sharp MX-C380P
Guide
44 pages
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Sharp MX-C380P and is the answer not in the manual?
Ask a question
Sharp MX-C380P Specifications
General
Brand
Sharp
Model
MX-C380P
Category
All in One Printer
Language
English
Related product manuals
Sharp MX-C311
849 pages
Sharp MX-C301
20 pages
Sharp MX-C303
64 pages
Sharp MX-C310
59 pages
Sharp MX-C300W
210 pages
Sharp MX-C301W
748 pages
Sharp MX-C304W
24 pages
Sharp MX-C303W
66 pages
Sharp MX-C358F
313 pages
Sharp MX-C300F
294 pages
Sharp MX-C304WH
64 pages
Sharp MX-C312
793 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
