4-7
TROUBLESHOOTING
5
Lower the lever at the front end of the
staple case.
6
Replace the staple case.
Push the staple case in
until it clicks
into place.
7
Slide the finisher back to the right.
Gently slide the finisher back to the right until it locks into its
original position.
8
Close the cover.
