MX-M260/M310/M260N/M310N MAINTENANCE 8 - 18
Note: Check to confirm that the solenoid shaft is in the gate bracket,
and fix with the screw.
H. Laser unit
Note: Do not disassemble the LSU unit.
(1) LSU
1) Turn OFF the machine power, and disconnect the power plug from
the power outlet.
2) Remove the left cabinet and exit tray.
3) Disconnect the LSU connector, and remove the securing screws to
remove the LSU.
1
2
1
2
1
1
1
2
1
2
1

Sharp MX-M260 Specifications

General

Print Technology	Laser
Print Speed	26 ppm
Max Print Resolution	600 x 600 dpi
Copy Speed	26 cpm
Max Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Warm-up Time	25 seconds
Fax Resolution	200 x 200 dpi
Paper Capacity	1, 100 sheets
Max Paper Size	A3
Duplex Printing	Yes
Functions	Print, Copy, Scan
Zoom Range	25% to 400%
Supported Paper Sizes	A4, A5, B5
Network Connectivity	Optional (Ethernet)
USB Connectivity	USB 2.0
Weight	28.5 kg
